Advancing knowledge and conservation of deep-sea habitats through strategic research and innovative solutions.

early life development physiology reproduction feeding growth rates ...

Deep-sea habitats are difficult to access

Understanding the fundamental biology of deep-sea organisms is crucial for identifying their roles in ecosystems and their sensitivity to human-induced pressures.

However, this information is challenging, if not impossible, to gather in their natural habitat

As a result, it is necessary to collect these organisms and study them ex-situ in specially designed aquaria with controlled environmental conditions

Strategic uses of Aquaria

Study of different aspects of cold-water coral biology, including their embryo and larvae development, and basic biological processes of reproduction, feeding and growth rates

Testing their sensitivities and recovery capacity to climate change (ocean warming, acidification and reduced food availability), and direct human pressures (fishing and potential deep-sea mining) using both the larvae and adult stages

Developing methodologies and techniques for the restoration of degraded cold-water coral communities

Environment simulation

The aquaria facilities are designed to provide a controlled environment for the study of deep-sea organisms, utilizing advanced technology to simulate natural conditions and support innovative research.

Temperature Control

14 °C Environment

The aquaria systems are maintained in a temperature-controlled room at 14 °C, ensuring optimal conditions for deep-sea organisms.

Independent Systems

Five Independent Aquaria

Composed of one semi-closed water system for maintenance and four open-water systems for experimentation.

Water Supply

Continuous Coastal Water Supply

Water is continuously pumped from coastal waters (5 m depth, salinity: 36) to maintain natural conditions.

Filtration System

Advanced Filtration

Water is filtered through a 50 µm felt filter bag and a 5 µm felt filter bag, followed by UV sterilization to ensure purity.

Cooling and Distribution

Efficient Cooling System

Water is cooled in sumps before being distributed to individual experimental aquaria, maintaining constant conditions.

Environmental Manipulation

Independent Manipulation of Conditions

Each system can independently adjust temperature, pH (via CO2 bubbling/removal), and oxygen levels to simulate climate change effects.

Feeding and Experimentation

Stock Tanks and Dosing Pumps

Equipped with 100 L stock tanks and dosing pumps for delivering sediments or food particles in various concentrations for experiments.

The "DeepSeaLab aquaria facilities" were conceived and designed in collaboration with Lisbon Oceanarium (Oceanário de Lisboa)

Species overwatch

Since 2009, we have gained experience in maintaining several cold-water corals, including scleractinians, gorgonians, soft corals, black corals, zoanthids and anemones.

These species are mostly found in deep-sea areas of the Atlantic Ocean and are key components of Azores deep-sea benthic communities.

Scleractinians

Lophelia pertusa
116 sightings Distribution map
OTU-2035
Madrepora oculata
357 sightings Distribution map
OTU-2036
Desmophyllum dianthus
106 sightings Distribution map
OTU-2031

Gorgonians

Dentomuricea aff. meteor
Viminella flagellum
1289 sightings Distribution map
OTU-2072 OTU-2078
Callogorgia verticillata
563 sightings Distribution map
OTU-2068
Acanthogorgia spp.
1320 sightings (related) Distribution map
OTU-2084 OTU-2164

Black Corals

Antipathella wollastoni
23 sightings Distribution map
OTU-2138

Soft Corals

Alcyonium spp.
10 sightings (related) Distribution map
OTU-2060 OTU-2126

Others

Zoanthids
Anemones

Techniques Used in Coral Research

Laboratory and Field Experiments

We conduct both laboratory experiments under controlled aquarium conditions and field experiments to study cold-water corals in their natural environment with a particular focus on supporting restoration efforts.

Techniques Employed

  • Closed-cell incubations to measure respiration and excretion rates
  • Biochemical and enzymatic analyses
  • Stable isotope analysis
  • Molecular biology techniques and bioinformatics to study coral gene expression responses
  • Investigation of the microorganisms associated with corals (the microbiome)

Supporting Restoration Efforts

Our research techniques are designed to provide insights that support restoration efforts for cold-water corals, ensuring their survival and resilience in changing ocean conditions.

Topics covered

  • Study the biology of key bioengineering cold-water coral species

    Study the biology of key bioengineering cold-water coral species Cold-water corals and important bioengineering species that enhance biological and functional diversity at the deep seafloor. Yet, there is limited information on their fundamental biology such as early life development, physiology, reproduction, feeding, and growth rates. Using aquaria-based experiments at the DeepSeaLab, we have studied fundamental aspects of the biology and ecophysiology of key habitat- forming octocorals in the Azores. Our research has focused on their reproductive biology and seasonality, larval development, as well as food preferences and metabolism. These studies provide essential insights into the reproductive potential and dispersal capabilities of larval stages, as well as their metabolic strategies. The findings have significant implications for understanding the ecology of these corals and their crucial roles in carbon and nitrogen cycling in the deep sea.

    Projects: ATLAS, iAtlantic, BioProtect
  • Climate change and cumulative stressors

    The deep ocean is increasingly under threat from multiple human activities, including fishing, oil and gas exploration, and prospective deep-sea mining. This human exploitation of ocean resources is happening in parallel with climate change in the oceans. Many areas of the deep seafloor are already becoming warmer, more acidic, less oxygenated, and with altered food inputs. Investigating the cumulative impacts of climate and human activities on cold-water corals is particularly pressing because of their low resilience to disturbance. We have been performing a series of aquaria-based experiments on different coral taxa (scleractinians, octocorals, antipatharians) to understand how the cumulative and potentially synergistic effects of these climate and human-made stressors may lead to loss of biodiversity, ecosystem functioning, and the provision of goods and services by deep-sea ecosystems.

    Projects: ATLAS, iAtlantic, BioProtect
  • Deep-sea mining

    While it has not taken place yet, the commercial exploitation of deep-sea mineral resources is considered one of the most pressing human threats to deep-sea ecosystems. We have been dedicated to understanding the effects of toxic sediment plumes produced during mining activities for polymetallic sulphides (PMS) on cold-water corals. We conducted a series of experimental studies exposing cold-water corals to suspended polymetallic sulphide particles. Our findings show that even low concentrations of these particles, or metals like copper released during mining, caused coral death within a short period (13-27 days). Additionally, these studies revealed delayed mortality in corals exposed to low concentrations of copper in seawater, suggesting that some coral species may not recover from the effects of PMS mining plumes. The results highlight the significant adverse impacts that mining can have on deep-sea ecosystems, and have been presented at the International Seabed Authority’s (ISA) Council meetings. We are continuing to work to develop environmental indicators of ecosystem health and thresholds for serious harm (e.g., metal toxicity or turbidity) as policy instruments for the environmental management and regulation of deep-sea mining.

    Projects: JPIOceans, DeepRisk, MIDAS
  • Ecological Restoration

    In some cases, conservation measures alone are insufficient to reverse the degradation of marine ecosystems, particularly in deep-sea ecosystems formed by cold-water corals characterized by slow growth, long longevity, and low fertility. In such situations, direct human intervention through ecological restoration is necessary to support ecosystem recovery. To address this, our team has been developing tools and techniques for the assisted regeneration, or active restoration, of coral gardens that may be impacted by human activities (e.g., seafloor mining, fishing). One methodology we have tested involves recovering corals accidentally captured during fishing, rehabilitating them at the DeepSeaLab, and then replanting them back on the seabed. The results indicate that this transplantation technique is successful, but they also show that the survival of transplanted corals depends on the coral species. Therefore, it is crucial to combine coral replanting with protection in marine protected areas to allow for the natural recovery of other corals. We are continuing this work with the goal of demonstrating that the involvement of professional fishermen in the recovery of accidentally captured corals and their subsequent replanting at sea could provide a low-cost alternative to traditional restoration actions. This initiative also helps raise awareness among local communities about the importance of protecting these vital ecosystems.

    Projects: MERCES, REDRESS

Highlighted publications

Beyond deep-sea mining sublethal effects: Delayed mortality from acute Cu exposure of the cold-water octocoral Viminella flagellum
Marine Pollution Bulletin
|
Oct, 2022

Authors list

10.1016/j.marpolbul.2022.114051

Inês Martins António Godinho Maria Rakka
Marina Carreiro-Silva
1 team member is author
Mechanical and toxicological effects of deep-sea mining sediment plumes on a habitat-forming cold-water octocoral
Frontiers in Marine Science
|
Oct, 2022

Authors list

10.3389/fmars.2022.915650

Marina Carreiro-Silva
Inês Martins Virginie Riou Joana Raimundo Miguel Caetano Raul Bettencourt Maria Rakka
Teresa Cerqueira
António Godinho
Telmo Morato
Ana Colaço
Contrasting metabolic strategies of two co-occurring deep-sea octocorals
Scientific Reports
|
May, 2021

Authors list

10.1038/s41598-021-90134-5

M. Rakka S. R. Maier D. Van Oevelen
A. Godinho
M. Bilan C. Orejas
M. Carreiro-Silva
2 team members are authors
Embryo and larval biology of the deep-sea octocoral Dentomuricea aff. meteor under different temperature regimes
PeerJ
|
Aug, 2021

Authors list

10.7717/peerj.11604

Maria Rakka António Godinho Covadonga Orejas
Marina Carreiro-Silva
1 team member is author
Molecular mechanisms underlying the physiological responses of the cold-water coral Desmophyllum dianthus to ocean acidification
Coral Reefs
|
Feb, 2014

Authors list

10.1007/s00338-014-1129-2

M. Carreiro-Silva
T. Cerqueira
A. Godinho
M. Caetano R. S. Santos R. Bettencourt
First insights into the embryo and larval biology of the antipatharian coral Antipathella wollastoni
Marine Biology
|
Mar, 2024

Authors list

10.1007/s00227-024-04412-7

Cold-water octocoral interactions with microplastics under laboratory conditions
Deep Sea Research Part I: Oceanographic Research Papers
|
Nov, 2024

Authors list

10.1016/j.dsr.2024.104400

João M. Pereira
Marina Carreiro-Silva
Anaïs Sire De Vilar António Godinho Ceri Lewis Christopher K. Pham
1 team member is author
